Standard features

LCD display
Hardware slot for two option cards
Operator access to audit trail, preset tare, accumulator, time and date and setpoints through menu keys
Password-protected audit trail tracking for configuration and calibration changes
Setpoints for control and alarms
Four onboard digital I/O channels
Filter settings for noise
Speed inputs

Specifications

Power Consumption: AC: 15 watts; DC: 20 watts
Excitation Voltage: 10 VDC 8 × 350 ohm (16 × 700 ohm) load cells
Analog Signal Input Range: -45 mV to 45 mV
Analog Signal Sensitivity: 0.3 µV/graduation minimum at 7.5 Hz; 1.0 µV/graduation typical at 120 Hz
Sample Rate: 7.5 to 120 Hz, software selectable
Resolution: Internal: 8,000,000 counts 23-bit Display: 100,000
System Linearity: ± 0.01% full scale
Digital I/O: Four I/O onboard primary keys, pseudo functions, batching functions
Communication Ports: RS-232 full duplex or RS-485 half duplex; USB 2.0 Micro B connector; Ethernet TCP/IP
Pulse Input: Dual inputs for redundancy 12 VDC
Display: LCD display, 0.8 in, seven-digit, seven-segment weight display, 3 × 20 pixelated prompt area
Annunciators: Load, total, rate, speed, zero
Keys/Buttons: Flat membrane panel, tactile feel
Temperature: Industrial: 14 °F to 122 °F (-10 °C to 50 °C)
Dimensions: (L x W x H) 9.93 × 4.00 × 8.94 in
Weight: 12 lb (5.4 kg)

Models & part numbers

Available configurations.

Part / model	Description
177708	120 VAC
180847	220 VAC Euro power cord

Options & accessories (7)

190527	Digital I/O
190528	Single analog
190529	Relay interface, not for totalizer pulse count output
177850	Panel mount option 880
197724	Overlay, clear protective
190531	DeviceNet®
190534	PROFIBUS®

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 150. Specifications are subject to change without notice.
