Standard features
- Comparator output (Hi/Ok/Lo) feature for manual or automatic operation as well as buzzer function
- GLP/GMP compliant software output
- Breeze break for maximum accuracy and fastest response
- Standard calibration weight
- Simple operator reference card provided
- Multi-weighing units
- Time and date clock function
- Data memory function for weighing, calibration, counting and Hi/Ok/Lo values
- Super Hybrid Sensor Technology (SHS)
- WinCT communication tools software
- RS-232 interface for connecting to printer or PC
Specifications
- Weighing Units
- Milligram, ounce, carat, pennyweight, troy ounce, grain (see technical manual for complete listings)
- Operating Modes
- Counting, percentage
- Power
- 120 VAC adapter, 11 VA
- Stabilization Time
- AD-4212A-100, AD-4212B-102: 0 to 30 g approx. 1.3 seconds 30 to 110 g approx. 1.3 seconds
- I/O Interface Comparator Output
- 3 level output with buzzer
- I/O Interface External Contact Input
- Re-zero and print
- Calibration Weight
- 50 g
- Connection Cable
- Approx. 2 m (between weighing unit and display unit)
- Temperature
- Operating: 41 °F to 104 °F (5 °C to 40 °C)
- Humidity
- 85% RH or less (no condensation)
- Est. Weight
- 8.5 lb (4 kg)
- Warranty
- Five-year limited
- Return Policy
- A&D Weighing standard policy - restock fee may apply
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| AD-4212A-100 | 110 g 0.1 mg 0.15 g ±0.3 mg |
| AD-4212B-201 | 210 g 0.1 mg 1 mg ±2 mg |
| AD-4212B-301 | 310 g 0.1 mg 1 mg ±2 mg |
Options & accessories (4)
| 97672 | AD-4212A-01 BCD output (factory installed, four month lead time) |
| 97674 | AD-4212A-07 Extension cable, 3 m |
| 97675 | AD-4212A-08 Ethernet interface with WinCT |
| 97676 | AD-4212A-19 Stainless steel breeze break (200 g only) |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 60. Specifications are subject to change without notice.
