Standard features
- Stable, accurate and fast operation, ensuring optimal weighing results
- Color touchscreen with 4.3 in (109 mm) display size
- Dual USB ports and RS-232 provide connectivity options
- Space-saving, top-mounted draft shield on analytical models
- Real-time clock with GLP/GMP data
- Below minimum sample weight indication with minimum weight feature
- AutoCal™ automatic internal adjustment weight for optimized weighing performance
Specifications
- Weighing Units
- Milligram, gram, kilogram, ounce, pound, carat, pennyweight, troy ounce, grain, newton, Hong Kong tael, Singapore tael, Taiwan tael, momme, tical, baht, mesghal, tola, custom
- Operating Modes
- Counting, weighing, dynamic weighing, checkweighing, percent weighing, totalization, display hold, density determination, formulation
- Power
- 100 to 240 VAC, 0.3 A, 50/60 Hz AC adapter
- Stabilization Time
- Approx. 1 second
- Calibration Weight
- AX223: 200 g AX423: 400 g AX523: 500 g AX622: 600 g
- Temperature
- Operating: 10 °C to 30 °C (50 °F to 86 °F)
- Est. Weight
- AX223, AX423, AX523: 12.8 lb (5.8 kg) AX622: 14.8 lb (6.5 kg)
- Warranty
- Two-year limited
- Return Policy
- OHAUS standard policy - restock fee may apply
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| AX223 | 220 g 0.001 g 0.001 g 0.2 mg |
| AX423 | 420 g 0.001 g 0.001 g 0.002 mg |
| AX622 | 620 g 0.01 g 0.001 g 0.002 mg |
Options & accessories (3)
| 191879 | 83021085 USB cable, Type A to B |
| 191875 | 80850043 Security device (laptop lock) |
| 70406 | 80500525 9-pin RS-232 cable (PC) |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 92. Specifications are subject to change without notice.
