Standard features
- Electronically controlled load (ECL) self-diagnostic before internal repeatability test without an external weight in less than 1.5 minutes
- Internal adjustment weight
- Impact shock detection
- Flow rate display
- RS-232 interface for connecting to printer or PC
- Password protection and anti-theft security slot
- GLP/GMP/ISO compliant to either AD-8127 printer or computer
- Transmits date, time, ID number, serial number, model, manufacturer and calibration data
- Rechargeable battery option for portability
- Super Hybrid Sensor Technology (SHS)
- Reverse backlit LCD display
- Optional glass breeze break
- Underweigh hook
Specifications
- Weighing Units
- Gram, ounce, pound, carat, pennyweight, troy ounce, grain (see technical manual for complete listing)
- Operating Modes
- Animal weighing, comparator function, ACAI counting function, percentage, density determination, statistical calculation
- Power
- 120 VAC adapter, Approx. 30 VA
- Stabilization Time
- GX-124A: Approx. 1.5 seconds GX-124AE: Approx. 2 seconds GX-224A, GX-224AE: Approx. 1 second GX-324A, GX-324AE: Approx. 2 seconds
- Display Refresh Rate
- 5 times/second, 10 times/second, 20 times/second
- Calibration Weight
- GX-124A, GX-124AE: 100 g GX-224A, GX-224AE, GX-324A, GX-324AE: 200 g
- Ionizer (fanless)
- AE versions come standard with built-in fanless ionizer with external touchless sensor
- Temperature
- Operating: 41 °F to 104 °F (5 °C to 40 °C)
- Humidity
- RH less than 85% (no condensation)
- Est. Weight
- 18 lb (8 kg)
- Warranty
- Five-year limited
- Return Policy
- A&D Weighing standard policy - restock fee may apply
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| GX-124A | 120 g 0.0001 g 0.0001 g ±0.0002 g |
| GX-224A | 220 g 0.0001 g 0.0001 g ±0.0002 g |
Options & accessories (13)
| 192662 | GXA-03 RS-232C Interface (D-sub 9-pin male) |
| 192663 | GXA-04 Comparator output (requires 192667) |
| 192667 | AX-K05692 MiniDIN 8-pin male for GXA-04 |
| 192671 | GXA-06 Analog output (includes 192673) |
| 192674 | GXA-09 Internal rechargeable battery (must be factory installed) |
| 192675 | GXA-10 Large glass breeze break |
| 192676 | GXA-12 |
| 192679 | GXA-23-PRINT External key input interface for SW:137-PRINT foot switch |
| 192680 | GXA-23-RZERO External key input interface for SW:137-REZERo foot switch |
| 192681 | GXA-23-PLUG External key input interface for AX-T-314A-S plug |
| 192682 | GXA-24 USB host interface (USB A type) |
| 192683 | GXA-25 External fanless ionizer (static eliminator) |
| 192684 | GXA-26 External IR switch (MiniDIN 4-pin male) |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 62. Specifications are subject to change without notice.
