Standard features

Heavy-duty designed mild steel base construction with 304 stainless steel cover
Polyurethane rubber leveling feet with stainless steel stems

Specifications

Load Cell: IP67, environmentally sealed Aluminum
Output Impedance: 350 ohm
Maximum Overload: 200%
Overload Protection: Five-point, independently adjusted
Scale Frame: Mild steel powder coated black
Scale Cover: AISI304L, straight line finish, Ra=45 ± 10
Cable Length: 10 ft (3 m)
Temperature: Compensated: 14 °F to 104 °F (-10 °C to 40 °C)
Warranty: Two-year limited
Approvals: NTEP 06-010, Class III 5,000 d Measurement Canada AM-5625 Load cell is cFMus approved

Models & part numbers

Available configurations.

Part / model	Description
93414	250 lb (125 kg) 30 × 30 × 8.75 in 300 lb
93415	500 lb (225 kg) 30 × 30 × 8.75 in 300 lb
93416	250 lb (125 kg) 36 × 36 × 8.75 in 330 lb
93417	500 lb (225 kg) 36 × 36 × 8.75 in 330 lb

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 175. Specifications are subject to change without notice.
