Standard features
- Simple operation, easy to set up
- Large six-digit backlight LCD display with 1-inch (29 mm) characters protected by heavy-duty tempered glass
- Powered USB HID point of sale interface, kg model only
- Nine-pin RS-232 interface for use with SMA and NCI protocols
- Four AA alkaline battery operation for portability
- Gravitational compensation allows for adjustment of factory calibration to meet your local gravity setting, non-approved
Specifications
- Power
- In-line power supply (included)
- Input
- 100 to 240 VAC, +10% -15%, 3-wire w/ground Terminated with standard USA 3-prong plug
- Output
- 12 V at 0.1 Amps DC minimum
- Frequency
- 50/60 Hz ± 3 Hz
- Power supply approvals
- UL, CE, EN, CUL
- Battery Type
- Four AA alkaline batteries, 6 V, with low battery indication at 4.3 volts
- Battery Life
- 50 to 250 hrs depending on backlight and auto-shutdown settings
- Excitation
- 3.0 mV/V
- Resolution
- Internal: 500,000 counts
- USB HID
- USB 2.0 full speed; Vendor ID: 1C19; Product ID: 0002
- Divisions (multi-range)
- DATE 0 to 5 kg × 0.001 kg 0 to 10 kg × 0.002 kg 0 to 35 kg × 0.01 kg
- lb/oz dual range
- 0 to 7 lb × 0.05 oz 0 to 70 lb × 0.2 oz
- Lb/oz dual interval
- 0 to 7 lb × 0.05 oz 7 to 70 lb × 0.2 oz
- Material
- Display: ABS plastic housing Scale base: Die-cast aluminum load bridge and base housing with stainless steel weight platter
- Dynamic Response
- Response time for stable weight: 0 to 1,000 d, 1,000 ms, maximum mean average 1,000 d +, 1,500 ms, maximum mean average
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| 187832 | 35 kg triple range 12 × 14 in 18 lb |
| 195741 | 35 kg triple interval 12 × 14 in 18 lb |
| 192361 | 70 lb dual range 12 × 14 in 18 lb |
| 195742 | 70 lb dual interval 12 × 14 in 18 lb |
Options & accessories (4)
| 174783 | Column bracket and post (12 × 14 scale only) 2 lb |
| 174784 | Second remote operator display, BenchPro BP-P with 68 in cable 4 lb |
| 183103 | 4 lb |
| 178501 | USB RS-232 serial adapter 3.28 ft cable 1 lb |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 186. Specifications are subject to change without notice.
