Standard features
- Membrane keypad consisting of: zero, units, print, tare, over, under, ID, target, 0-9, clear, decimal, enter, menu, power
- 304 stainless steel
- PreVent™ breather vent
- Storage for up to 50 IDs
- Unit of measure: kg, g, lb, oz, lb/oz (lb/oz is not Legal for Trade)
- High-intensity LED display
- Battery backed time and date
- Two full-duplex RS-232 serial ports
- Configurable print formats
- Audit trail tracking
- Optional communications: Ethernet, USB or fiber optic
- Four configurable Digital I/O
- Auto-print capability
- Accumulator
Specifications
- Power AC
- Line Voltages: 115/230 VAC
- Frequency
- 50/60 Hz
- Power Consumption
- 1.5 A at 115 VAC (8 W) 0.75 A at 230 VAC (8 W)
- Measurement Rate
- 960, 480, 240, 120, 60, 30, 15, 7.5 per second
- System Linearity
- ±0.01% full scale
- Digital I/O
- Four channels on CPU board
- Circuit Protection
- RFI, EMI, ESD protection
- Display
- Large 0.8 in, 14 segment, six digit high-intensity red LED display
- Scale Frame
- AISI304L, straight line finish, Ra=45 ± 10
- Scale Cover
- AISI304L, straight line finish, Ra=45 ± 10
- Annunciators
- Designators for %, kg, gm, lb, oz, center of zero, G/B, N, T, PT, neg, motion
- Temperature
- Certified: 14 °F to 104 °F (-10 °C to 40 °C)
- Rating/Material
- IP66, stainless steel
- Resolution
- Display: 100,000
- Load Cell
- Aluminum, environmentally sealed
- Warranty
- Two-year limited
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| 105957 | † 5 × 0.001 lb (2.5 × 0.0005 kg) or (80 × 0.02 oz) 10 × 10 × 4.25 in 12 in |
| 105958 | † 10 × 0.002 lb (5 × 0.001 kg) or (160 × 0.05 oz) 10 × 10 × 4.25 in 12 in |
| 105959 | † 25 × 0.005 lb (10 × 0.002 kg) or (400 × 0.1 oz) 10 × 10 × 4.25 in 12 in |
| 105960 | † 25 × 0.005 lb (10 × 0.002 kg) or (400 × 0.1 oz) 12 × 12 × 4.25 in 12 in |
| 105961 | † 50 × 0.01 lb (25 × 0.005 kg) or (800 × 0.2 oz) 12 × 12 × 4.25 in 12 in |
| 105962 | † 100 × 0.02 lb (50 × 0.01 kg) or (1,600 × 0.5 oz) 12 × 12 × 4.25 in 12 in |
| 118891 | † 2.5 × 0.0005 kg (5 × 0.001 lb) or (80 × 0.02 oz) 10 × 10 × 4.25 in 12 in |
| 118892 | † 5 × 0.001 kg (10 × 0.002 lb) or (160 × 0.05 oz) 10 × 10 × 4.25 in 12 in |
| 118893 | † 10 × 0.002 kg (25 × 0.005 lb) or (400 × 0.1 oz) 10 × 10 × 4.25 in 12 in |
| 118896 | † 25 × 0.005 kg (50 × 0.01 lb) or (800 × 0.2 oz) 12 × 12 × 4.25 in 12 in |
| 118897 | † 50 × 0.01 kg (100 × 0.02 lb) or (1,600 × 0.5 oz) 12 × 12 × 4.25 in 12 in |
| 106123 | †† 3 × 0.001 kg 254 × 254 × 108 mm 305 |
| 106124 | †† 6 × 0.002 kg 254 × 254 × 108 mm 305 |
| 106125 | †† 15 × 0.005 kg 254 × 254 × 108 mm 305 |
| 106126 | †† 15 × 0.005 kg 305 × 305 × 108 mm 305 |
| 106128 | †† 60 × 0.02 kg 305 × 305 × 108 mm 305 |
Options & accessories (6)
| 200578 | Ethernet TCP/IP and cable with attached cord grip |
| 77142 | Ethernet TCP/IP card |
| 206272 | Wireless LAN card RS232/Wi-Fi 802.11 a/b |
| 171968 | Firmware download cable |
| 78026 | Fiber-optic, duplex cable 100 ft |
| 80892 | Fiber-optic cutter |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 304. Specifications are subject to change without notice.
