Standard features

DeviceNet communication adapter
125 Kbps, 150 Kbps and 500 Kbps baud rate
Onboard diagnostic LEDs
Active module with serial and parallel application interface
Complete Modbus TCP server
Up to eight bytes of I/O data
Transformer isolated interface 100 Mbps full duplex Ethernet
CE and UL compliant

Specifications

Power: 3.3 VDC, 250 mA
Connector Type: Pluggable screw terminal
IP Address Range: MAC ID 0 to 63
Diagnostic LEDs: Module status and network status
Dimensions: 2.00 × 1.90 × 0.75 in (52 × 49 × 19 mm)
Temperature: Operating: -40 °F to 158 °F (-40 °C to 70 °C)
Power Requirements: 3.3 VDC, 250 mA

Models & part numbers

Available configurations.

Part / model	Description
179162	DeviceNet interface kit for 880 indicator 1 lb
165793	DeviceNet interface kit for 1280 indicator 1 lb
190531	DeviceNet interface kit for 882D and 882IS indicators 1 lb
179161	Modbus TCP Interface kit for 880 indicator (single port) 1 lb
205568	Modbus TCP Interface kit for 880 indicator (dual port) 1 lb
165796	Modbus TCP Interface kit for 1280 indicator (single port) 1 lb
190533	Modbus TCP Interface kit for 882D and 882IS indicators 1 lb

Options & accessories (2)

156783	Additional operating manual
156782	Additional operating manual

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 553. Specifications are subject to change without notice.
