Standard features
- Backlit weight display
- Remote zeroing
- Easy-to-install NiCAd battery option
- RS-232 interface for connecting to printer or PC
Specifications
- Weighing Units
- Carat, pennyweight, troy ounce, newton, decimal ounce, decimal pound
- Operating Modes
- Counting, percentage
- Power
- 120 VAC adapter (optional Ni-MH battery pack)
- Stabilization Time
- < 2 seconds
- Display Type
- Seven segment LCD with backlight (character height 16 mm)
- Calibration Weight
- EK-120i: 120 g EK-200i: 200 g EK-300i: 300 g EK-410i: 400 g EK-610i: 400 g EK-2000i: 2,000 g EK-3000i: 3,000 g EK-4100i: 4,000 g EK-6100i: 6,000 g
- Temperature
- Operating: 14 °F to 104 °F (-10 °C to 40 °C)
- Humidity
- Less than 85% RH (non-condensing)
- Est. Weight
- 3.5 lb (1.5 kg)
- Warranty
- Five-year limited
- Return Policy
- A&D Weighing standard policy - restock fee may apply
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| EK-120i | 120 g 0.01 g 0.01 g ±0.01 g |
| EK-200i | 200 g 0.01 g 0.01 g ±0.01 g |
| EK-410i | 400 g 0.01 g 0.01 g ±0.02 g |
| EK-610i | 600 g 0.01 g 0.01 g ±0.02 g |
| EK-2000i | 2,000 g 0.1 g 0.1 g ±0.1 g |
| EK-4100i | 4,000 g 0.1 g 0.1 g ±0.2 g |
| EK-6100i | 6,000 g 0.1 g 0.1 g ±0.2 g |
Options & accessories (8)
| 97760 | EKW-04i Comparator/relay outputs/buzzer |
| 97761 | EKW-07i Underhook for EK-4100i/6100i/6000i/12Ki/EW-12Ki |
| 97762 | EKW-09i NiCAd battery pack |
| 97764 | AX:3005824-5S Protective dust cover (not in use) |
| 97605 | AD-100-2 Anti-theft device |
| 97766 | TB:662 AC adapter (120 V) |
| 97767 | TB:164 AC adapter (240 V) |
| 151247 | AD-1688 Data logger |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 77. Specifications are subject to change without notice.
