Standard features
- Backlit LED touchscreen
- User-friendly operation
- Basic applications
- Monolithic weighing systems
- Aluminum die-cast base, ABS housing
- Front level bubble
- RS-232 standard
- Below balance weighing
Specifications
- Weighing Units
- Gram, kilogram, ounce, pound, carat, pennyweight, troy ounce, grain, newton (see technical manual for complete listing)
- Operating Modes
- Weighing, density, percentage, counting, mass unit conversion
- Power
- AC adapter, 115 to 240 V, US plug
- Stabilization Time
- 2.5 seconds
- Calibration Weight
- BCE64I-1S: 50 g BCE124I-1S: 100 g BCE224I-1S: 200 g
- Temperature
- Operating: 5 °C to 40 °C (41 °F to 104 °F)
- Humidity
- 15% to 80% for temperatures up to 31 °C
- Est. Weight
- 13.7 lb (6.2 kg)
- Warranty
- Two-year limited
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| BCE124I-1S | 120 g 0.1 mg ±0.1 mg ±0.2 mg |
| BCE224I-1S | 220 g 0.1 mg ±0.1 mg ±0.2 mg |
Options & accessories (6)
| 112261 | YDP20-OCE Data printer (printer requires power supply part number 191429) |
| 31103 | 6906937 Paper rolls, one roll |
| 31106 | 6906918 Ink ribbon cassette |
| 201911 | YCC-D09MF Data Cable RS-232, DB-9M to DB-9F (For YDP20 Printer) |
| 204042 | YEPS01-PS8 |
| 191429 | YEPS01-PS4 |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 122. Specifications are subject to change without notice.
