Standard features

High-speed printing
Single copy and up to five-part
Wide slip capability of A4 size documents
Remote-printing functionality sent via RS-232
Supports double-strike commands

Specifications

Print Speed: 2.8 lines per second printing for 88 columns of print 4.9 lines per second printing for 40 columns of print
Print Width: 5.2 in
Paper Dimensions: (L × W) 2.76 × 2.76 in/11.69 × 8.26 in (70 × 70 mm/297 × 210 mm)
Paper Thickness: 0.003 to 0.014 in (0.09 to 0.36 mm)
Interfaces: Serial: Bidirectional parallel, RS-232 (DB-25F)/ RS-485 USB
Power: 24 VDC ± 10%
Ribbon: ERC-31 (purple)
Dimensions: (L × W × H) 10.47 × 9.92 × 7.28 in (266 × 252 × 185 mm)
Warranty: One-year limited (includes printhead)
Approvals: CE Listed FCC cULus Listed

Models & part numbers

Available configurations.

Part / model	Description
68502	12 lb
128726	12 lb
164391	TM-U590, 115/230 VAC power supply, cool white 12 lb

Options & accessories (12)

68525	Ink cartridge (purple) ERC-31
104145	Ink cartridge (black) ERC-31B
23112	Power supply, U.S. version PS-180
128746	Power supply, European version of PS-180
111840	Protective dust cover
68562	Additional operating manual
68725	Technical manual
72309	Power supply, 12 VDC vehicle cigarette plug
15568	25-pin D-sub male to 25-pin D-sub male RS-232 serial interface cable
15547
41279
32810

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 877. Specifications are subject to change without notice.
