Standard features

Industrial protocol for Allen-Bradley® PLC and other EtherNet/IP compliant devices
IP address settings configurable with ip config utility, web page, ARP or DHCP
Supports Allen-Bradley EtherNet/IP
Onboard diagnostic LEDs
CE marked and UL conformance
AOP (880 only) or standard EDS file download
Two RJ-45 EtherCAT 100 Mbit/s ports available simultaneously
Can be wired in several topologies including star, line or tree
Has built-in redundancy that compensates for potential breaks in wiring
No network switches necessary, can be wired directly from device to device
Includes self-terminating network
CE, cULus and RoHS compliant

Specifications

Power Requirements: 3.3 VDC, 250 mA
IP Address Range: Full IP address range
Connector Type: RJ-45
Diagnostic LEDs: Module status and network status
Dimensions: 2.00 × 1.90 × 0.75 in (52 × 49 × 19 mm)
Temperature: Operating: -40 °F to 158 °F (-40 °C to 70 °C)
Power: 3.3 VDC, 500 mA

Models & part numbers

Available configurations.

Part / model	Description
208129	EtherNet/IP Interface kit for 1280 indicator (dual Port) 1 lb
179158	EtherCAT interface kit for 880 indicator 1 lb
179533	EtherCAT interface kit for 1280 indicator 1 lb
190535	EtherCAT interface kit for 882D and 882IS indicators 1 lb

Options & accessories (2)

156861	Additional operating manual
164394	Additional operating manual

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 554. Specifications are subject to change without notice.
