Standard features
- Touchless IR (infrared) sensors minimize keypad use
- Program IR sensor to control operations including print, tare and other selectable functions
- Color VGA, 5.7 in display with icons for simple menu navigation
- Multiple application modes designed for versatility
- AutoCal™ calibration
- Robust IP54 die-cast metal bottom housing with stainless steel pan
- ENERGY STAR qualified adapter
- Underweigh hook
Specifications
- Weighing Units
- Gram, kilogram, ounce, pound, carat, pennyweight, grain (see technical manual for complete listing)
- Operating Modes
- weighing, counting, animal/dynamic weighing, checkweighing, percent weighing, filling, parts counting, totalization, formulation, differential weighing, density determination, peak hold, ingredient costing, SQC
- Power
- AC adapter input: 100 to 240 VAC 0.6 A 50/60 Hz
- Stabilization Time
- Approx. 1 second
- Calibration
- AutoCal™ at 1.5 °C temperature change, 11 hours, and external calibration
- Temperature
- Operating: 14 °F to 140 °F (-10 °C to 60 °C)
- Est. Weight
- 25 lb (12.5 kg)
- Warranty
- Two-year limited
- Return Policy
- OHAUS standard policy - restock fee may apply
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| Ex12001 | 12,000 g 0.1 g ±0.1 g ±0.2 g |
| Ex35001 | 35,000 g 0.1 g ±0.1 g ±0.2 g |
Options & accessories (4)
| 157238 | 30078082 Tower mount display |
| 77712 | 80500524 RS-232 cable, PC 25-pin to EX |
| 70406 | 80500525 RS-232 cable, PC 9-pin to EX |
| 156234 | 46001724 Multi-range AC adapter |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 109. Specifications are subject to change without notice.
