Standard features
- IP65/NEMA Type 4
- RS-232 interface for connecting to printer or PC
- Quick reference operation card
- Time and date
- Vacuum fluorescent display (VFD)
- Interval time setting
- Underweigh hook
Specifications
- Weighing Units
- Pound, carat, pennyweight, troy ounce, grain, decimal ounce, pound/ounce operating modes, counting, percentage
- Power
- 120/240 V AC adapter
- Stabilization Time
- Approx. 1.5 seconds (typical in FAST mode)
- Display Refresh Rate
- 5 times/second or 10 times/second
- Calibration Weight
- GF-8202M/MD: 2 to 8 kg GF-10202M: 2 to 10 kg GF-12001M: 5 kg, 10 kg GF-22001M: 5 kg, 10 kg, 20 kg GF-32001M/MD: 5 kg, 10 kg, 20 kg, 30 kg
- Temperature
- Operating: 41 °F to 104 °F (5 °C to 40 °C)
- Humidity
- RH less than 85% (no condensation)
- Est. Weight
- 18.3 lb (8.3 kg)
- Warranty
- Five-year limited
- Return Policy
- A&D Weighing standard policy - restock fee may apply
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| GF-10202M | 10.2 kg 0.01 g 0.01 g ±0.03 g |
| GF-12001M | 12.2 kg 0.1 g 0.1 g ±0.2 g |
| GF-22001M | 22.2 kg 0.1 g ±0.2 g 0.1 g |
| GF-32001MD | 6.2/32.2 kg 0.1/1 g ±0.5 g/0.1 g 0.2 g/1 g |
Options & accessories (6)
| 97784 | GX-07K** Waterproof cable for standard RS-232C |
| 97605 | AD-100-2 Anti-theft device |
| 97785 | AX:073007197A Protective in-use cover |
| 97649 | TB:648 AC adapter (120 V/220 V) |
| 151247 | AD-1688 Data logger |
| 196128 | AD-8127 Impact dot matrix, statistical printer, includes cable |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 80. Specifications are subject to change without notice.
