Standard features
- LED onboard for testing data transmission
- Captures data and stores it on a USB flash drive (up to 8 GB not included)
- Transfer data to your PC using the USB flash drive
- Text file examples (actual text will be dependent on transmitted file)
- 02:50PM 11/13/2012 GROSS 58 lb
- 02:50PM 11/13/2012 GROSS 68 lb
Specifications
- Power
- Requires 5 VDC, 2 A
- Baud Rate
- 9600
- Data Bits
- 8
- Parity
- None
- Customer Supplied
- Power and USB flash drive
- Industrial Enclosure Option
- 7.5 × 7.5 × 4.5 in (19 × 19 × 12 cm) Latch for lock
- Warranty
- One-year limited
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| 153265 | go-between board, requires 5 volts |
| 153266 | go-between industrial enclosure, requires 5 volts |
| 153267 | go-between desk enclosure, power supply included |
Options & accessories (7)
| 154797 | Adapter, power 5 VDC 2A 90 to 264 VAC, U.S. plug, cULus |
| 195607 | USB flash drive, 8 GB |
| 130789 | Null model DB9 adapter female to male |
| 119064 | Null modem adapter, DB9 F/F |
| 50764 | Straight cable, DB9 F/F |
| 22436 | DB9 cable to blunt end |
| 15493 | Cable four-conductor/ft |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 135. Specifications are subject to change without notice.
