Standard features
- Internal adjustment weight
- IP65 protection
- RS-232 interface for connecting to printer or PC
- Data-collection software
- Auto re-zero function
- Flexible display positions
- Time and date
- Bright blue, fluorescent display
- Adjustable swing arm display
- Die-cast aluminum body with stainless weighing pan
- Detached digital weight indicator (KS models only)
Specifications
- Weighing Units
- Carat, pennyweight, troy ounce, grain, decimal ounce, decimal pound, pound/ounce
- Operating Modes
- Counting, percentage
- Power
- Approx. 30 VA (supplied to the AC adapter)
- Stabilization Time
- Approx. 1.5 seconds (typical in FAST mode)
- Height with Column
- 652 mm
- Temperature
- Operating: 41 °F to 104 °F (5 °C to 40 °C)
- Humidity
- RH less than 85% (no condensation)
- Est. Weight
- Approx. 39.7 lb (18 kg)
- Warranty
- Five-year limited
- Return Policy
- A&D Weighing standard policy - restock fee may apply
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| GX-12001L | 12 kg 0.1 g 0.1 g ±0.2 g |
| GX-22001L | 22 kg 0.1 g 0.1 g ±0.2 g |
| GX-32001LD | 6.2 kg 0.1 g 0.1 g ±0.2 g |
| GX-42001L | 42 kg 0.5 g 0.5 g ±1 g |
Options & accessories (15)
| 97607 | AD-1682 Rechargeable battery pack |
| 97608 | AD-8920 Universal remote display |
| 97813 | GP-04 Comparator output with buzzer |
| 97814 | GP-06 Analog output (replaces standard RS-232C) |
| 97815 | GP-07 GP extension cable (factory installed 120 day lead time) |
| 97816 | GP-20 Underhook GP-12 kg thru 40 kg |
| 97817 | GP-21 Underhook GP-60 kg thru 102 kg |
| 97605 | AD-100-2 Anti-theft device |
| 97820 | 07:3004753 Protective in-use cover |
| 97614 | TB:137 AC adapter (220 V) |
| 97609 | AD-8922 Remote controller |
| 102904 | GP-12 Animal weighing pan |
| 151247 | AD-1688 Data logger |
| 97612 | SW:128 Foot switch |
| 196128 | AD-8127 Impact dot matrix, statistical printer, includes cable |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 81. Specifications are subject to change without notice.
