Standard features

Display and control multiple ScaleCore based scales, indicators, remote displays and receivers through network connected devices using a web browser, including cell phones, tablets and PCs
Capable of functioning either with an existing Wi-Fi network or as its own Wi-Fi router
Can be powered by a dedicated power input or directly through the Ethernet cable where PoE (Power over Ethernet) is supported
RS-232 communications at up to 460 Kbps
Scale/load cell summing
Tiered login to limit scale functionality for different levels of users (Contact MSI for application consultation)

Specifications

Power: 5 to 6 VDC, 7 to 14 VDC, 85 to 265 VAC, PoE
Effective Range: Typically 100 to 300 ft, line of sight; for longer range consult factory
Minimum System Requirements: Will display on any device with a web browser supporting HTML 5 Connected ScaleCore based MSI scales and indicators are required to have the optional Wi-Fi radio modul
Connectivity: Wi-Fi 2.4 GHz IEEE 802.11g Gigabit Ethernet 2 × USB 2.0 Interface RS-232 Serial
Status Annunciators: Units (lb, kg, short tons (tn), metric tons (t), (NONE) gross/net, motion, center of zero
Enclosure: IP65, aluminum black powder coated (excludes 85 to 265 VAC model)
Temperature: Operating: 14 °F to 104 °F (-10 °C to 40 °C)
Warranty: One year limited
Approvals: NTEP 21-098 Classes III and IIIL at 10,000d

Models & part numbers

Available configurations.

Part / model	Description
207943	ScaleCore Webserver, 5 VDC and PoE
209704	ScaleCore Webserver, 7 to 14 VDC and PoE
210817	ScaleCore Webserver, 85 to 265 VAC and PoE wall cube

Options & accessories (2)

213559
224240	Webserver Access Point, more than 8 devices

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 805. Specifications are subject to change without notice.
