Standard features
- Simple and easy to operate, adapts to your environment
- GLP/GMP/GCP/ISO compliant which outputs the calibration data and ID number of the balance for calibration confirmation to the AD-8121B printer
- Internal adjustment weight
- System diagnostic to alert operator of abnormal weighing conditions
- Weighing chamber
- RS-232 interface for connecting to printer or PC
- Data memory function
- Time and date function
- WinCT communication tools software
- Liquid crystal display (LCD)
- Underweigh hook
Specifications
- Weighing Units
- Carat, pennyweight, troy ounce, decimal ounce (see technical manual for complete listing)
- Operating Modes
- Percentage, counting
- Power
- 120 VAC (AC adapter) 50/60 Hz, 11 VA (110, 220, 240 available by special order)
- Stabilization Time
- Approx. 3.5 sec (0.1 mg)/8 sec (0.01 mg)
- Calibration Weight
- GH-120: 50 g/100 g GH-200: 100 g/200 g GH-300: 100 g/200 g/300 g
- Temperature
- Operating: 41 °F to 104 °F (5 °C to 40 °C)
- Humidity
- 85% RH or less (no condensation)
- Est. Weight
- Approx. 18 lb (8.2 kg)
- Warranty
- Five-year limited
- Return Policy
- A&D Weighing standard policy - restock fee may apply
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| GH-120 | 120 g 0.0001 g ±0.2 mg 0.1 mg |
| GH-200 | 220 g 0.0001 g ±0.2 mg 0.1 mg |
| GH-300 | 320 g 0.0001 g ±0.3 mg 0.2 mg |
Options & accessories (5)
| 97604 | GH-08 Ethernet option |
| 97606 | AD-1653 Density determination kit |
| 97608 | AD-8920A Universal remote display |
| 97609 | AD-8922A Remote controller |
| 97612 | SW:128 Foot switch |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 56. Specifications are subject to change without notice.
