Standard features
- NTEP Certified and Measurement Canada Approved models available
- RL20000 alloy steel load cell standard (prices include load cell and ITCM load cell assembly)
- Mild steel construction, black paint finish
- Stainless steel, hermetically sealed load cells available
- Custom sizes and capacities available from 5,000 to 60,000 lb
Specifications
- End Load Capacity
- 100% full scale
- mV/V Output
- 1.50 to 1.87 mV/V nominal
- Cable Length
- 20 ft (6.1 m)
- Warranty
- One-year limited
- Approvals
- NTEP 94-126 Class III/IIIL Measurement Canada Approved, AM-5114, Legal For Trade on sizes greater than 1.6 m, or a capacity greater than 10,000 kg
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| 29586 | 60 1/2 × 66 in 528 lb |
| 29588 | 66 1/2 × 91 in 640 lb |
| 29589 | 64 × 64 in 538 lb |
| 35008 | 62 × 92 in 561 lb |
| 35009 | 62 × 105 in 720 lb |
| 40409 | 72 × 72 in 618 lb |
| 83433 | 64 3/4 × 64 3/4 in 567 lb |
| 46264 | 62 5/8 × 62 5/8 in 405 lb |
| 46265 | 60 1/2 × 66 in 550 lb |
| 50172 | 64 × 64 in 550 lb |
| 50173 | 62 × 92 in 680 lb |
| 50174 | 62 × 105 in 720 lb |
| 39152 | 5 × 5 ft 1,885 lb |
| 39153 | 6 × 6 ft 1,975 lb |
| 39154 | 7 × 7 ft 2,220 lb |
| 39155 | 8 × 8 ft 2,310 lb |
| 39157 | 10 × 10 ft 2,635 lb |
| 39158 | 5 × 5 ft 2,010 lb |
| 39159 | 6 × 6 ft 2,120 lb |
| 39160 | 7 × 7 ft 2,385 lb |
| 39161 | 8 × 8 ft 2,495 lb |
| 39162 | 9 × 9 ft 2,750 lb |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 810. Specifications are subject to change without notice.
