Standard features

Stainless steel stem for corrosion resistance
Heavy-duty construction, low-cost replacement feet
Four standard diameters all with 1/2-20 UNF stainless steel stud, slotted for top-access applications
Stainless steel jam nut provided
Top of stud is machined undersize 10% for easy alignment into load cell Carbon steel
Bright zinc and clear chromate plating for corrosion resistance
Active ball suspension provides ideal load cell loading with maximum side load protection
Hardened alloy steel with plated finish
Includes one jam nut in carbon steel and stainless steel feet
Top of stud is machined undersized 10% for easy alignment into load cell plus slotted for top-access applications Stainless steel
Provides outstanding accuracy, repeatability and performance
Active ball suspension provides optimal load cell performance
Hardened stainless steel material, welded with polished finish
Top of stud is machined undersized 10% for easy alignment into load cell plus slotted for top-access applications

Models & part numbers

Available configurations.

Part / model	Description
74586	2.00 in 3.00 in
73801	3.00 in 3.00 in
74578	1.87 in 1/2-20 UNF 3.50 in
74579	2.00 in 1/2-20 UNF 3.50 in
74580	2.50 in 1/2-20 UNF 3.50 in
74581	3.00 in 1/2-20 UNF 3.50 in
74582	3.00 in 3/4-16 UNF 4.50 in
74583	3.00 in 1-12 UNF 4.50 in
74584	3.00 in 1-14 UNF 4.50 in
173018	4.40 in 3/4-16 UNF 3.13 in
174937	5.40 in 3/4-16 UNF 4.13 in
74572	1.87 in 1/2-20 UNF 3.50 in
74573	2.00 in 1/2-20 UNF 3.50 in
73800	2.50 in 1/2-20 UNF 3.50 in
74574	3.00 in 1/2-20 UNF 3.50 in
74575	3.00 in 3/4-16 UNF 4.50 in
74576	3.00 in 1-12 UNF 4.50 in
175615	3.47 in 1/2-20NF 2.62 in

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 434. Specifications are subject to change without notice.
