Standard features

AC or DC operation
Easy-to-read 0.8 in (20 mm) LED red or green (sunlight visible)
Three enclosure types or panel mount kit
Four annunciators
Full floating decimal point
Compatible with a variety of digital weighing indicators; DIP switch selectable intuitive data receiver interprets serial strings

Specifications

Display: 6-digit, 7-segment, 0.8 in (20 mm) LED Red (standard intensity) Green (sunlight visible)
Annunciators: lb, kg, gross, net
Operating Voltage: 115 VAC, 230 VAC available DC voltage Range: 6.2 to 18 VDC
Input Interface: RS-232, 20 mA active or passive current loop ASCII compatible
Baud Rate: Selectable: 300, 600, 1200, 2400, 4800, 9600, 19200
Temperature: Operating: -13 °F to 104 °F (-25 °C to 40 °C)
Rating/Material: NEMA Type 4X FRP or stainless steel
Weight: Approximately 5 lb (2.3 kg) Stainless steel unit, approximately 8 lb (3.6 kg)
Warranty: One-year limited

Models & part numbers

Available configurations.

Part / model	Description
32716	RD-232, 115 VAC/12 VDC, FRP enclosure, red LED 5 lb
68786	5 lb
32717	8 lb
178169	5 lb
178171	RD-232, 220 VAC/12 VDC, FRP enclosure, no power cord, green LED 5 lb

Options & accessories (1)

33210

Additional operating manual (RD-232/RD-300)

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 904. Specifications are subject to change without notice.
