Standard features
- Self-contained HID reader with Weigand to RS-232 converter with power supply
- Indoor/outdoor
- Use with 920i®, 1280 indicators and kiosk systems
- Requires special programming
- Discreet hands-free authentication solution for long range parking, gate control and truck identification
- IP65 rating allows outdoor mounting
- Supports Wiegand standards
- Requires Wiegand converter, consult with a sales engineer with application specifics
Specifications
- Power Supply
- 120 VAC input at 10 W, 5 VDC Output 2 at amp
- Read Range*
- 2.5 to 4.5 in (6.3 to 11.4 cm) with HID iCLASS® card 1.0 in (2.5 cm) with HID iCLASS key 1.0 in (2.5 cm) with HID iCLASS tag 1.5 to 2.0 in (3.8 to 5.0 cm) with HID iCLASS prox 1 to 2 in (2.5 to 5.0 cm) with MIFARE® card (serial number only) *Using ISO 15693 mode (except MIFARE®). Dependent upon installation conditions. Please note that all iCLASS credentials are available in either a 2 K bits (256 Bytes) or 16Kbits (2 KBytes) configuration.
- Transmit Frequency
- 13.56 MHz
- Cable Distance
- RS-232-C 50 ft
- Current Requirements (Avg/Peak)
- 80/260 mA at 12 VDC
- Material
- FRP
- Dimensions
- (L × W × H) 10.50 × 8.91 × 6.25 in (267 × 226 × 159 mm)
- Temperature
- Operating: -31 °F to 150 °F (-35 °C to 65 °C)
- Humidity
- 5 to 95% RH (non-condensing)
- Weight
- 8.8 oz (249.5 g)
- Pending Certifications
- Taiwan, Singapore, Germany VdS
- Approvals Power Supply
- CE Marked TUV UL61010/cUL CSA C22.2 o. 107.1 UL1604: Class I Div 2 EN 50175 LVD: EN662368 EMC: Directive EN61204-3 EMI: Class B, EMS Industrial
- Pending Approvals HID
- Taiwan, Singapore, Germany VdS
- Approvals HID
- UL 294/cUL FCC Certification Canada Certification CE Mark (Europe) New Zealand Australia c-Tick
- Read Range
- 9.8 to 16.4 ft (3 to 5 m)
- Color
- Black
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| 220144 | HID Box, remote |
| 184458 | |
| 184466 | Windshield mount |
| 220769 | |
| 225411 | Mount, for use only when mounting with kiosk pole and swing-arm |
| 226003 | Kit, wallmount bracket |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 28. Specifications are subject to change without notice.
