Standard features
- Fully self-contained, integrated reader
- Ideal for truck scales, and parking and access control applications
- 915 MHz RF band operation
- Compatibility with a wide range of industry- standard formats
- Weatherproof enclosure
- Quick, simple installation by trained, authorized personnel
- Programmable RF power
- Compatible with a variety of RFID tag options including half and full frame RFID tags (beam or battery powered) as well as windshield RFID tag options (beam or battery powered)
- Asymmetrical broadcast pattern
- Low-profile design
- UV-tolerant and corrosion-resistant construction
Specifications
- Input Power
- 16 to 20 VAC, 47 to 63 Hz, or 16 to 28 V DC
- Vibration
- 0.5 grams, 10 to 500 Hz
- Frequency Range
- 902 to 928 MHz
- RF Control
- By sense output or host command
- Polarization
- Linear, horizontal
- Read Range
- Read performance varies depending on tag and reader configuration and environment Read range for all the SmartPass E4 Reader is 12 ft (3.7 m) typical to 17 ft (3.7 m) maximum
- I/O Control
- Input: Two independent dry contact closures for sense circuits Output: Two independent Form-C contacts
- Mounting Surface
- Mount to pole or wall, indoor or outdoor
- Enclosure
- Tamper-proof, polycarbonate housing
- Temperature
- Operating: -40 °F to 131 °F (-40 °C to 55 °C)
- Humidity
- 100% condensing
- Dimensions
- (L × D × W) 15.5 × 15.5 × 3.25 in (393 × 393 × 83 mm)
- Weight
- 9.5 lb (4.3 kg)
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| 108201 | SmartPass E4 reader only |
| 162431 | 18 VAC power supply |
| 86401 | 5 ft interface cable |
| 162430 | 20 ft interface cable |
| 86403 | 35 ft interface cable |
| 162432 | Pole/wall mount bracket |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 29. Specifications are subject to change without notice.
