Standard features

Manage up to four load cells (one scale)
Dual encoders and outputs for automatic test weight application
Micro-USB communication port for configuration, diagnostics and data backup (RL Tools Software)
All data and adjustments of each scale are available through integrated fieldbus (not available on AN models)
Removable terminal blocks to simplify wiring in the electrical panel
Power supply circuit with protections, specific for industrial environment

Specifications

Power: 12 to 24 VDC
Power Consumption: 5 W
Excitation Voltage: 5 VDC, 120 mA (up to 16 × 350 ohm cells)
Analog Signal Input Range: ±39 mV
Analog Signal Sensitivity: 0.3 µV/graduation minimum
Sample Rate: Single-channel up to 2,600 Hz, software selectable 4 channels up to 100 Hz, software selectable
Analog Output (if equipped): Opt. isolated, 16-bit 0 to 20 mA, 4 to 20 mA (maximum 350 ohm) 0 to 5 VDC, 0 to 10 VDC (minimum 10,000 ohm)
Digital I/O: Two inputs: 12/24 VDC Two outputs: 150 mA 48 VAC/150 mA 60 VDC
Communication Ports: (1) RS-485 half duplex, (1) RS-232 full duplex 1 USB Micro B connector (device) for PC configuration
Pulse Input: Dual inputs for redundancy
Display: Six-digit 0.31 in (8 mm), red LED
Keys/Buttons: Flat membrane panel, tactile feel
Dimensions: (L × W × H) Overall: 10.5 × 6.26 × 12.5 in (266 × 159 × 318 mm)
Mounting Tabs: 8.0 × 13.12 in (203 × 333 mm)
Weight: 27 lb
Rating/Material: NEMA 4X (if using supplied enclosure)

Models & part numbers

Available configurations.

Part / model	Description
225172
225173
225174
226132	Analog output, 24 VDC power supply, terminal blocks
226133	Modbus TCP/IP, 24 VDC power supply, terminal blocks
226134	PROFINET, 24 VDC power supply, terminal blocks

Options & accessories (1)

88792

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 154. Specifications are subject to change without notice.
