Standard features
- Two-color printing (software enabled)
- Small footprint
- Easy load "drop-in and print" paper loading
- Adjustable paper width
- Logo storage utility for easy logo data
- Drawer kickout device function
- Cutter
- Easy to change "cartridge-type interface" from RS-232 (DB-25F) to parallel
Specifications
- Print Speed
- 7 in (177.8 mm) per second, 60 lines per second at 3 mm per line (180 mm/sec)
- Print Width
- 2.83 in (80 mm) Optional: 2.05 in (52 mm), 3.15 in (80 mm)
- Resolution
- 203 dpi (8 dots/mm)
- Bar Codes
- UPC-A/E, JAN/EAN-8/13, Code 39/93/128, Codabar (NW7)
- Paper Width
- Adjustable 3.15 in (80 mm) Optional: 3.25 in (82.5 mm)
- Paper Thickness
- 0.003 to 0.0 06 in (0.065 to 0.150 mm)
- Roll Diameter
- 3.5 in (90 mm)
- Paper Roll Core
- 0.50 to 1.00 in (12 to 25.4 mm)
- Printer Reliability
- 60 million lines MCBF (CRT)
- Interface
- RS-232 serial DB-25F
- Temperature
- Operating: 41 °F to 113 °F (5 °C to 45 °C)
- Dimensions
- (W × H × D) 5.79 × 5.83 × 8.39 in (147 × 148 × 213 mm)
- Warranty
- Parts: Three-year limited Printhead: One-year limited
- Approvals
- FCC cULus Listed
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| 69907 | *TSP743 II, RS-232 with power supply, 115/230 VAC 8 lb |
| 69908 | *TSP743 II, RS-232 only, 24 VDC 8 lb |
| 85929 | *TSP743 II, parallel without power supply 8 lb |
Options & accessories (10)
| 69903 | Power supply, PS-60-24A |
| 69917 | One-ply thermal, (W) 3.125 in (75.44 mm, 2.97 in dia.) 7/16 in core 230 ft |
| 107041 | MaxStick receipt paper for TSP654 3 1/8 in wide 150 ft long adhesive strip |
| 71355 | Parallel cartridge option |
| 69919 | Wall mount bracket |
| 70598 | Label, DTL, (W × L × D) 3 × 1 × 4 in, with black line timing mark 1,600 labels/roll |
| 70597 | Label, DTL, (W × L × D) 3 × 2 × 4 in, with black line timing mark 900 labels/roll |
| 15547 | Blunt end, 25-pin D-sub male RS-232 serial interface cable (Rice Lake indicators) |
| 15568 | 25-pin D-sub male to 25-pin D-sub male RS-232 serial interface cable |
| 72440 | 25-pin to nine-pin D-sub female cable |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 880. Specifications are subject to change without notice.
