Standard features
- Loop diagnostics
- Loop isolation transformer
- Loop conditioner
- Aluminum RF shield housing
- Surge protection
- Loop frequency counter
- 10 gold-plated sensitivity controls
- Eight gold-plated function controls
- Six gold-plated controls for frequency, reset and frequency counter
- Two high-intensity LED indicators
- Two relays—relay 2 is pulse or presence
- Rugged and flexible TPE tubing
- Electronic lightning protection of vehicle detectors
- Comes standard with 50 ft of twisted and jacketed lead-in wire
Specifications
- Power
- 12 VAC/DC, 24 VAC, 24 VDC, 110 VAC, 220 VAC, maximum current draw 100 mA
- Output Relays
- 5A/125 VAC standard version, 1A/125 VAC low current version
- Connector
- 86CP11 compatible with 11-Pin Octal DIN-rail mountable socket or wire harness
- Enclosure Material
- Extruded anodized aluminum
- Enclosure Dimensions
- (L × W × H) 3.25 × 2.56 × 3.65 in (83 × 40 × 90 mm)
- Loop Dimensions
- 4 × 6 ft thru 4 × 12 ft standard, custom sizes available
- Loop Diameter
- 0.26 in
- Lead-in-Wire
- 50 ft long, twisted wire in PVC jacket
- Temperature
- Operating: -40 °F to 180 °F (-40 °C to 82 °C)
- Loop Approvals
- UL subject 13, Type PLTC 300 V, 90 °C passes IEEE-328,210,000, BTU Flame Test Pennsylvania, Bureau of Deep Mine Safety, Approval P-MWMS-1-85
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| 171093 | |
| 86758 | Loop, vehicle detection preformed, 4 ft x 10 ft loop, 50 ft lead in wire |
| 86601 |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 37. Specifications are subject to change without notice.
