Rice Lake · Software Systems
WeighVault®
Web Application with Middleware Services
Standard features
- Specialized PC software makes data entry easy
- Boost product ID storage to nearly limitless potential, and manage as many scales as necessary
- Eliminates front-panel entry of ID parameters
- Quickly program, edit and manage scales and each unique product ID right from your PC
- Stores the details of each transaction for either a single scale or multiple scales
- Collects data as transactions occur and provides detailed transaction and productivity reports
- Allows users to add, edit and access IDs over a network connection
- A supported web browser (Google® Chrome®, Microsoft® Edge®, Mozilla® Firefox® or Apple® Safari®)
- Extend reach of WeighVault application
- Gain efficiencies for programmers integrating application specific content
- Enterprise dashboard view points
- Useful weight data related to IDs
- Boost system usage
Specifications
- Minimum System Specifications
- CW-90X or Counterpart® Also compatible with 1280 using counting and checkweighing programs 800+ MHz Intel® compatible processor 1 GB of RAM 750 MB hard drive space TCP/IP connections to a CW-90, CW-90X or Counterpart
- Recommended System Specifications
- 1.0 GHz Intel compatible processor 2 GB of RAM 4 GB hard drive space Windows® 10 or newer (x64 systems) TCP/IP connections to a CW-90, CW-90X or Counterpart
- Network Requirements
- The PC running the WeighVault service must have a static IP address Known IP address and subnet of the host PC; if connecting via WLAN, known network SSID and security settings (pass keys and phrases) Network policy must allow passwords of six characters
- Data Registers
- • ID code [32 characters • Unit weight [6 places • Tare weight [6 places • Units field • Parts name [32 characters • Part description [32 characters • Lot number [32 characters • Location [12 characters • Inventory quantity [7 characters
- Reports
- • Part • Inventory • Activity • Location
- Part Fields
- • Product ID [4 characters • Two descriptions fields [32 characters each • Target • Tare • Over • Under • Units
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| 117358 | Software package, WeighVault for CW-90/90X |
| 125546 | Software package, WeighVault for Counterpart |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 930. Specifications are subject to change without notice.
