Standard features

Amber backlit LCD display, 0.8 in
Three-way unit toggle; 10x higher resolution toggle
External calibration routine
RS-232C
One scale connection

Specifications

Power Requirements: 120 to 240 VAC, 17 W / 23 VA maximum
Excitation Voltage: 9 V
Load Cell Connection: Four- or six-wire
Annunciators: On/Off, Zero, Tare, Print/Data
Keys/Buttons: Gross/Net toggle
Dimensions: (L × W × H) 11.9 × 7.4 × 3.5 in (302 × 188 × 90 mm)
Temperature: Operating: 14 °F to 104 °F (-10 °C to 40 °C)
Rating/Material: AISI 304 stainless steel IP44, IP69K
Warranty: Two-year limited, pending evaluation

Models & part numbers

Available configurations.

Part / model	Description
102396	CAISL1-U IP44 protection rated 7.5 lb
102398	CAIS1-U IP69K protection rated 7.5 lb
115668	CAISL1-UV1 IP44, controller for IS base 7.5 lb
115671	CAIS1-UV1 IP69K, controller for IS base 7.5 lb

Options & accessories (11)

105607	YDH02CISUS Wall mount bracket
171727	YDH12CWSUS Bench mount bracket
156440	YDH01CWSUS Post mount assembly for 10 × 10 in platforms, 13 in high
156441	YDH02CWSUS Post mount assembly for 12 × 12 in platforms, 19 in high
156442	YDH03CWSUS Post mount assembly for 18 × 18 in platforms, 29 in high
103049	YAS02MI 24 V industrial power supply
162640	YDO02C-ETH Ethernet TCP/IP
155826	YDO02C-AO Analog output, 0-20 mA, 4-20 mA, 0-10 V
155804	YCC05-001M2 RS-232 9/25-pin D-Sub female, 1.5 m, IP44
155805	YCC01-USBM2 RS-232 to USB connector, 2 m IP44
155806	YCC02-D25F6 RS-232 open to 25 D-Sub female

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 835. Specifications are subject to change without notice.
