Standard features

Backlit LCD display
Keypad with two IDs for entering identifier codes and preset tare
Info key for quick and easy display of tare input and ID codes
Date/time fully integrated
GMP/GLP printable record
Platform toggling and four function keys
Bar graph weighing range indicator
Application data and totalization memory stored in battery-backed RAM
Optional bar code scanner for preset tare, reference weight and ID entry
Stored customer-specific data records
Key for toggling between weighing applications, and five soft keys with text-supported user guidance
Input functions for entering up to four alphanumeric ID texts

Specifications

Power Requirements: 120 to 240 VAC, 17 W / 23 VA maximum
Excitation Voltage: 9 V
Load Cell Connection: Four- or six-wire
Annunciators: Gross/Net toggle
Keys/Buttons: On/Off, Zero, Tare, Print/Data
Dimensions: (L × W × H) 11.9 × 7.4 × 3.5 in (302 × 188 × 90 mm)
Temperature: Operating: 14 °F to 104 °F (-10 °C to 40 °C)
Rating/Material: AISI 304 stainless steel IP44, IP69K
Warranty: Two-year limited, pending evaluation

Models & part numbers

Available configurations.

Part / model	Description
102405	CAISL3-U IP44 protection rated 7.5 lb
102407	CAIS3-U IP69K protection rated 7.5 lb
115674	CAIS3-UV1 IP69K, controller for IS base 7.5 lb

Options & accessories (9)

171727	YDH12CWSUS Bench mount bracket
156441	YDH02CWSUS Post mount assembly for 12 × 12 in platforms, 19 in high
156442	YDH03CWSUS Post mount assembly for 18 × 18 in platforms, 29 in high
103049	YAS02MI 2 V industrial power supply
155826	YDO02C-A0 Analog output, 0-20 mA, 4-20 mA, 0-10 V
162640	YDO02C-ETH Ethernet TCP-IP
193049	YDC01CI Dust cover pack of two
155804	YCC05-001M2 RS-232 9/25-Pin D-Sub female, 1.5 m, IP44
155806	YCC02-D25F6 RS-232 open to 25 D-Sub female

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 837. Specifications are subject to change without notice.
