Standard features

Can be used in areas where explosive gas and dust mixtures occur
Documentation to verify intrinsic safety available upon request
Built for easy cleaning and disinfection
Meets HACCP and FDA requirements for the food industry
Pit frames for flush mounting available
High resolution of 30,000 d

Specifications

Indicator Option: CIXS3-U
Temperature: Operating: 14 °F to 104 °F (-10 °C to 40 °C)
Rating/Materials: NEMA Type 4, IP67 Load cells IP68, hermetically sealed
Cable Length: Up to 30 × 30: 10 ft 36 × 36 and over: 20 ft
Warranty: Two-year limited, pending evaluation
Approvals: FM approved Classes 1,2,3, Division 1, Groups ABCDEGFT4, US and Canadian hazardous areas, when used with CISX3-U or FCT01-X indicator

Models & part numbers

Available configurations.

Part / model	Description
100919	CAPXS1U-10CC 10 × 10 in 2.37 in 1 15 lb 0.0005 lb
100920	CAPXS1U-20CC 10 × 10 in 2.37 in 1 30 lb 0.001 lb
100921	CAPXS1U-50CC 10 × 10 in 2.37 in 1 60 lb 0.002 lb
100923	CAPXS1U-100DD 12 × 12 in 3.87 in 1 150 lb 0.005 lb
100925	CAPXS1U-100EE 18 × 18 in 3.5 in 1 150 lb 0.005 lb
100926	CAPXS1U-200EE 18 × 18 in 3.5 in 1 200 lb 0.01 lb
100934	CAPXS4U-250GG 24 × 24 in 3.31 in 4 300 lb 0.01 lb
100935	CAPXS4U-500GG 24 × 24 in 3.31 in 4 600 lb 0.02 lb
100943	CAPXS4U-500HH 30 × 30 in 3.31 in 4 600 lb 0.02 lb
100944	CAPXS4U-1000HH 30 × 30 in 3.31 in 4 1,500 lb 0.05 lb
100945	CAPXS4U-1000KK 36 × 36 in 3.75 in 4 1,500 lb 0.05 lb
100946	CAPXS4U-2500KK 36 × 36 in 3.75 in 4 3,000 lb 0.1 lb
100949	CAPXS4U-2500NN 48 × 48 in 3.75 in 4 3,000 lb 0.1 lb
100950	CAPXS4U-5000NN 48 × 48 in 3.75 in 4 6,000 lb 0.2 lb

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 851. Specifications are subject to change without notice.
