Standard features

Mild or stainless steel wheeled frame, base and mast
Diamond tread top plate, mild or stainless steel
Large rubber wheels (not rated for IS) simplify movement on uneven floors
Two IP67 aluminum load cells
Standard indicator mount with integral handles for the 380/380X Synergy, 880/880 Plus, 680 Synergy and 381 Synergy

Specifications

End Load Capacity: 100% end loading
Cable length: 9 ft 10 in (3 m)
mV/V Output: 2 mV/V
Weighing Platter: 4.5 in height when in weigh mode
Column Height: 59 in
Warranty: Weldment: Five years Load cells: Two years All other components: One year
Approvals: NTEP Certified, 98-004, Class III, 2,500 d Measurement Canada, AM-5218

Models & part numbers

Available configurations.

Part / model	Description
41293	24.25 × 30.375 in 31 × 41 × 4.5 in 500 lb 336 lb
41294	24.25 × 30.375 in 31 × 41 × 4.5 in 1,000 lb 356 lb
41295	24.25 × 30.375 in 31 × 41 × 4.5 in 2,000 lb 373 lb
211285	24.25 × 30.375 in 31 × 41 × 4.5 in 500 lb 336 lb
211286	24.25 × 30.375 in 31 × 41 × 4.5 in 1,000 lb 356 lb
211287	24.25 × 30.375 in 31 × 41 × 4.5 in 2,000 lb 373 lb
41297	24.25 × 30.375 in 31 × 41 × 4.5 in 1,000 lb 356 lb

Options & accessories (5)

43376	500/1,000 lb mild steel ramp 9º
43378	2,000 lb mild steel ramp 9º
43377	Ramp assembly, 500/1,000 lb, stainless steel, 27 × 25 in 7.2º
43379	Ramp assembly, 2,000 lb, stainless steel, 27 × 25 in 7.2º
41371	Mounting bracket for 882IS/882IS Plus with battery

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 372. Specifications are subject to change without notice.
