Standard features

Live side rails
Top-access foot adjustment holes
Holes are 1/2-13 threaded for lifting scale
Four adjustable stainless steel SUREFOOT™ support feet
Treaded top plate
Alloy steel load cells

Specifications

End Load Capacity: 1,000 lb: 100% full scale 2,500 lb: 80% full scale
Cable Length: 10 ft (3 m)
Junction Box: TuffSeal® JB4SS stainless steel, NEMA Type 4X junction box with signal trim card
Welding: Stitch
Threaded Eyebolt: Hole (1/2-13 NC) located in center of deck for easy lifting
Warranty (limited): Weldment: Five years Load cells: Two years All other components: One year
Approvals: NTEP 03-060, Class III 2,500 d Measurement Canada AM-5578 (500 kg) Class III 2,500 d (1,000 kg) Class III 2,000 d

Models & part numbers

Available configurations.

Part / model	Description
77962	30 × 31 in 1,000 lb (500 kg) 205 lb
77963	30 × 31 in 2,500 lb (1,000 kg) 205 lb
77964	36 × 37 in 1,000 lb (500 kg) 265 lb
78021	For use with 30 × 31 in scale 90 lb
78022	For use with 36 × 37 in scale 100 lb
199103	36 × 37 in 30 lb
78015	29.25 × 12 in (sold individually) 8.7º 25 lb

Options & accessories (2)

214612
214613

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 369. Specifications are subject to change without notice.
