Standard features

Live side rails
Top-access foot adjustment holes
Four adjustable stainless steel SUREFOOT™ support feet
Diamond tread top plate
Alloy steel load cells

Specifications

End Load Capacity: 1,000 lb: 100% full scale 2,500 lb: 80% full scale
Cable Length: 10 ft (3 m)
Junction Box: TuffSeal® JB4SS stainless steel, NEMA Type 4X junction box with signal trim card
Welding: Stitch
Threaded Eyebolt: Hole (1/2-13 NC) located in center of deck for easy lifting
Warranty (limited): Weldment: Five years Load cells: Two years All other components: One year
Approvals: NTEP 03-060, Class III 2,500 d Measurement Canada AM-5578 (500 kg) Class III 2,500 d (1,000 kg) Class III 2,000 d

Models & part numbers

Available configurations.

Part / model	Description
77962	30 × 31 in 1,000 lb (500 kg) 205 lb
77963	30 × 31 in 2,500 lb (1,000 kg) 205 lb
77964	36 × 37 in 1,000 lb (500 kg) 265 lb
77965	36 × 37 in 2,500 lb (1,000 kg) 265 lb
78011	30 × 12 in (sold individually) 7.2º 25 lb
78012	36 × 12 in (sold individually) 7.2º 30 lb

Options & accessories (5)

18777	Floor anchor plates, mild steel, set of 2 (for use with static scale, without ramps)
19352	Floor stand for indicator, 36.3 in high, mild steel (for use with static scale)
126384	Floor stand for indicator, 48 in high, mild steel
214612	Back stop and mounting hardware for 30 in wide scale
214613	Back stop and mounting hardware for 36 in wide scale

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 368. Specifications are subject to change without notice.
