Standard features

Live side rails
Top-access foot adjustment holes
Four adjustable stainless steel SUREFOOT™ support feet
Smooth top plate
Stainless steel, IP66 load cells

Specifications

End Load Capacity: 1,000 lb: 100% full scale 2,500 lb: 80% full scale
Cable Length: 10 ft (3 m)
Scale Weldment: AISI304L, glass bead blasted for even appearance
Junction Box: TuffSeal® JB4SS stainless steel, NEMA Type 4X junction box with signal trim card
Welding: Stitch, consult factory if continuous is required
Threaded Eyebolt: Holes are 1/2-13 threaded for lifting scale
Warranty (limited): Weldment: Five years Load cells: Two years All other components: One year
Approvals: NTEP CC 03-060, Class III 2,500 d Measurement Canada AM-5578 (500 kg) Class III 2,500 d (1,000 kg) Class III 2,000 d

Models & part numbers

Available configurations.

Part / model	Description
77967	30 × 31 in 1,000 lb (500 kg) 205 lb
77968	30 × 31 in 2,500 lb (1,000 kg) 205 lb
77969	36 × 37 in 1,000 lb (500 kg) 265 lb
77970	36 × 37 in 2,500 lb (1,000 kg) 265 lb
78013	30 × 12 in (sold individually) 7.2º 25 lb
78014	36 × 12 in (sold individually) 7.2º 30 lb

Options & accessories (4)

18778	Floor anchor plates, stainless steel, set of 2 (for use with static scale, without ramps)
28740	Floor stand for indicator, 36.3 in high, stainless steel (for use with static scale)
214614	Back stop and mounting hardware for 30 in wide scale
214615	Back stop and mounting hardware for 36 in wide scale

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 370. Specifications are subject to change without notice.
