Standard features

Unique flexure design filters motion and shock loading
Spring steel flexures
Rugged all-steel painted construction smooth deck
One RL20000 series nickel-plated s-beam load cell and plated wire rope
NTEP Certified models in sizes 24 × 24 in (500 lb) through 72 × 96 in up to 10,000 lb capacity Stainless Steel
All 304 stainless steel construction, smooth deck
Stainless flexures, hardware and load cell
NTEP Certified models in sizes 24 × 24 in (500 lb) through 72 × 96 in up to 10,000 lb capacity

Specifications

End Loading Capacity: 100% of scale capacity
Safe Overload Capacity: 150% of scale capacity
Warranty: Two-year limited
Approvals: Painted: NTEP 88-100, Class III 5,000 d Stainless steel: NTEP 88-100, Class III 3,000 d

Models & part numbers

Available configurations.

Part / model	Description
33134	18 × 24 × 6.5 in 500 lb (250 kg) 125 lb
33066	18 × 24 × 6.5 in 1,000 lb (500 kg) 125 lb
113566	18 × 30 × 6.5 in 500 lb (250 kg) 133 lb
113567	18 × 30 × 6.5 in 1,500 lb (750 kg) 133 lb
33067	24 × 24 × 6.5 in 500 lb (250 kg) 151 lb
33068	24 × 24 × 6.5 in 1,000 lb (500 kg) 151 lb
33138	30 × 30 × 6.5 in 500 lb (250 kg) 191 lb
33069	30 × 30 × 6.5 in 1,000 lb (500 kg) 191 lb
33139	30 × 30 × 6.5 in 1,500 lb (750 kg) 191 lb
33070	30 × 30 × 8.25 in 2,000 lb (1,000 kg) 281 lb
33140	36 × 36 × 8.25 in 1,000 lb (500 kg) 234 lb
33071	36 × 36 × 8.25 in 2,000 lb (1,000 kg) 234 lb
33072	36 × 36 in × 8.25 in 5,000 lb (2,500 kg) 234 lb
113569	38 × 46 × 8.25 in 2,000 lb (1,000 kg) 610 lb
113570	38 × 46 × 8.25 in 5,000 lb (2,500 kg) 610 lb
113572	48 × 48 × 8.25 in 1,000 lb (500 kg) 654 lb
33073	48 × 48 × 8.25 in 2,000 lb (1,000 kg) 654 lb
33074	48 × 48 × 8.25 in 5,000 lb (2,500 kg) 654 lb
33075	48 × 48 × 9.25 in 10,000 lb (5,000 kg) 735 lb
33078	48 × 60 × 9.25 in 10,000 lb (5,000 kg) 845 lb
33149	48 × 72 × 9.25 in 5,000 lb (2,500 kg) 1,120 lb
33081	60 × 60 × 8.25 in 5,000 lb (2,500 kg) 967 lb
33083	60 × 72 × 10.25 in 10,000 lb (5,000 kg) -
113581	24 × 24 × 6.5 in 500 lb (250 kg) 151 lb
113582	24 × 24 × 6.5 in 1,000 lb (500 kg) 151 lb
113586	30 × 30 × 8.25 in 2,000 lb (1,000 kg) 281 lb
113588	36 × 36 × 8.25 in 2,000 lb (1,000 kg) 450 lb
113595	48 × 48 × 8.25 in 5,000 lb (2,500 kg) 630 lb
113604	48 × 60 × 8.25 in 5,000 lb (2,500 kg) -
113613	60 × 72 × 11.25 in 10,000 lb (5,000 kg) 1,290 lb

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 377. Specifications are subject to change without notice.
