Standard features
- Painted mild steel
- Diamond tread scale top plate and ramps
- Live side rails
- Self-centering ball and load receiver plate load introduction
- Top-access junction box
- Four alloy steel, environmentally sealed, single-ended load cells
Specifications
- End Load Capacity
- 100% full scale at 2,000 lb
- Cable Length
- 20 ft (6.1 m) for connecting junction box to indicator
- Junction Box
- EL204 signal trim
- Welding
- Stitch, consult factory if continuous is required
- Threaded Eyebolt
- Two holes (1/2-20 NF)
- Weighing Surface Dimensions
- (L × W × H) 72.00 × 36.00 × 1.81 in
- Warranty
- Two-year limited
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| 204615 | 36 × 72 in 2,000 × 0.5 lb 12º 565 lb |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 365. Specifications are subject to change without notice.
