Standard features

Low-profile design
20 ft SURVIVOR® EL147HE hostile environment load cell cable
Top-access junction box
Four adjustable, stainless steel SUREFOOT™ support feet
Four stainless steel, IP66 shear beam load cells

Specifications

End Load Capacity: 80% full scale at 2,500 lb 100% full scale at 5,000 lb
Cable Length: 20 ft (6.1 m) for connecting junction box to indicator
Scale Weldment: AISI304L, glass bead blasted for even appearance
Junction Box: TuffSeal® JB4SS stainless steel, NEMA Type 4X junction box with signal trim card
Welding: Stitch, consult factory if continuous is required
Warranty (limited): Load cells: Two years All other components: One year

Models & part numbers

Available configurations.

Part / model	Description
177910	48 × 48 × 3 in 2,500 lb 200 lb
177911	48 × 60 × 3 in 2,500 lb 210 lb
177912	60 × 60 × 3 in 2,500 lb 235 lb
177913	48 × 48 × 3 in 5,000 lb 200 lb
177914	48 × 60 × 3 in 5,000 lb 210 lb
177915	60 × 60 × 3 in 5,000 lb 235 lb

Options & accessories (2)

18778	Floor anchor plates, stainless steel (set of 2)
178250	Wheel kit option (wheels engage at a 28° angle)

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 367. Specifications are subject to change without notice.
