Standard features

Rugged washdown design
304 stainless steel construction
Rigid stainless steel tube frame
Four stainless steel, hermetically sealed, IP69K shear beam load cells
Load cells protected on all four sides
20 ft (6 m) of SURVIVOR® EL147HE hostile environment load cell cable
Remote junction box can be located up to 10 ft away from scale
Four adjustable stainless steel SUREFOOT™ support feet
Removable polyethylene deck (deck weight: 80 lb (36.6 kg) on 4 × 4 ft size)
Side brackets to hold deck during washdown

Specifications

End Load Capacity: 100% full scale at 2,000 lb and 5,000 lb 80% full scale at 10,000 lb
Cable Length: 20 ft (6.1 m) for connecting junction box to indicator
Scale Weldment: AISI304L, glass bead blasted for even appearance
Junction Box: TuffSeal® JB4SS stainless steel, NEMA Type 4X junction box with signal trim card
Welding: Continuous
Warranty (limited): Weldment: Five years Load cells: Two years All other components: One year
Approvals: NTEP 92-001, Class III 5,000 d

Models & part numbers

Available configurations.

Part / model	Description
50385	2.5 ft × 2.5 ft × 4.4 in 2,000 lb 158 lb
50386	3 ft × 3 ft × 4.4 in 2,000 lb 208 lb
50387	4 ft × 4 ft × 4.4 in 2,000 lb 338 lb
50388	4 ft × 4 ft × 4.4 in 5,000 lb 338 lb
50389	4 ft × 4 ft × 5.4 in 10,000 lb 447 lb
50390	4 ft × 5 ft × 4.4 in 2,000 lb 406 lb
50391	4 ft × 5 ft × 5.4 in 5,000 lb 406 lb
50392	4 ft × 5 ft × 5.4 in 10,000 lb 540 lb
50393	4 ft × 6 ft × 5.4 in 2,000 lb 477 lb
50394	4 ft × 6 ft × 5.4 in 5,000 lb 477 lb

Options & accessories (2)

28740	Floor stand for indicator, 36.3 in high, stainless steel
18778	Floor anchor plates, stainless steel (set of 2)

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 364. Specifications are subject to change without notice.
