Standard features

Compact scale built as custom
Three indicator models: 6, 14 or 28 keys
Three weighing technologies: load cell, mechatronic or monolithic
Resolution 35,000 to 350,000 d
Built-in motorized calibration weight (Signum Supreme)
RS-232 output

Specifications

Power: Multi-range, 110 to 240 V
Temperature: Operating: 14 °F to 104 °F (-10 °C to 40 °C)
Measurement Technology: SIWRDCP-Load cell signum regular SIWADCP-Mechatronic cell-advanced SIWSDCP-Monolythic-supreme
Rating/Material: IP65 Painted steel frame with a stainless steel cover
Cable Length: Display: 6 ft (1.83 m) approximately
Platform Size: 13.8 × 9.5 in (351 × 241 mm)
Warranty: Two-year limited, pending evaluation

Models & part numbers

Available configurations.

Part / model	Description
103665	SIWADCP-V3 13.7 × 9.5 in 1 7 kg 0.1
103666	SIWADCP-V4 13.7 × 9.5 in 3 7 kg 0.1
105853	SIWADCP-V5 13.7 × 9.5 in 3 35 kg 0.5
105854	SIWADCP-V6 13.7 × 9.5 in 3 65 kg 1 g
105855	SIWRDCP-V6 13.7 × 9.5 in 1 3 kg 0.1
103657	SIWRDCP-V7 13.7 × 9.5 in 1 6 kg 0.2
103658	SIWRDCP-V8 13.7 × 9.5 in 1 15 kg 0.5
103659	SIWRDCP-V9 13.7 × 9.5 in 1 35 kg 1 g
103660	SIWRDCP-V10 13.7 × 9.5 in 1 60 kg 2 g
151372	SIWSBBP-V16 7.1 × 7.1 in 1 3 kg 0.01
151378	SIWRDCP-V22 13.7 × 9.5 in 3 35 kg 1 g
151410	SIWADCP-V24 13.7 × 9.5 in 1 16 kg 0.2
151411	SIWADCP-V25 13.7 × 9.5 in 1 35 kg 0.5

Options & accessories (9)

31106	6906918 Ribbon
31103	6906937 Paper
83248	YCC01-0016M3 Cable, 9.8 ft, 12-pin round to 25 D-Sub female
105607	YDH02CISUS Wall mount bracket
153218	YDH01P Column for DC platforms, 19 in
155884	YDH02P Column to BBP
193048	YDC01SW Dust cover pack of two
194664	YDO01CS-ETH Ethernet option (for DCP & EDG models only)
199894	YDO03SW-ETH Ethernet option (for BBP models only)

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 833. Specifications are subject to change without notice.
