Standard features

Four NTEP Certified alloy steel shear beam load cells
Top access junction box
Diamond safety tread plate deck
Four adjustable rigid polyurethane rubber feet, 3 in (76 mm) diameter
Signal trim summing board housed in ABS enclosure
Threaded eyebolt hole (1/2-20NF) located in the center of the deck for easy lifting
20 ft of EL147 load cell cable. The load cell cable exits weldment toward the interior of scale, allowing flexibility to route out any side of scale to digital weight indicator.

Specifications

End Load Capacity: 100% full scale at 2,000 lb and 5,000 lb 80% full scale at 10,000 lb
Cable Length: 20 ft (6.1 m) for connecting junction box to indicator
Threaded Eyebolt: Hole (1/2-20 NF) located in center of deck for easy lifting
Warranty (limited): Weldment and load cells: Two-years All other components: One-year
Approvals: NTEP 92-001A9, Class III 5,000 d Measurement Canada AM-5530, Class III 5,000 d (2,500 kg, 5,000 kg) 2,000 d (1,000 kg)

Models & part numbers

Available configurations.

Part / model	Description
74715	3 ft × 3 ft × 3.625 in 2,000 lb 190 lb
74716	4 ft × 4 ft × 3.625 in 2,000 lb 305 lb
74717	4 ft × 4 ft × 3.625 in 5,000 lb 305 lb
74718	4 ft × 4 ft × 3.625 in 10,000 lb 305 lb
74719	4 ft × 5 ft × 3.625 in 5,000 lb 395 lb
74721	4 ft × 6 ft × 3.625 in 5,000 lb 470 lb
74723	5 ft × 5 ft × 3.625 in 5,000 lb 505 lb
74724	5 ft × 5 ft × 3.625 in 10,000 lb 575 lb
77440	3 ft × 3 ft × 3.625 in 1,000 kg 190 lb
77373	4 ft × 4 ft × 3.625 in 1,000 kg 305 lb
77346	4 ft × 4 ft × 3.625 in 2,500 kg 305 lb
77347	4 ft × 4 ft × 3.625 in 5,000 kg 305 lb
82880	4 ft × 5 ft × 3.625 in 2,500 kg 395 lb
77348	5 ft × 5 ft × 3.625 in 2,500 kg 505 lb
77349	5 ft × 5 ft × 3.625 in 5,000 kg 575 lb

Options & accessories (3)

75819	Floor anchor plates, mild steel (set of two)
19352	Floor stand for indicator, 36.3 in high, mild steel
126384	Floor stand for indicator, 48 in high, mild steel

Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 380. Specifications are subject to change without notice.
