Standard features
- Three- or four-point onboard system, RL20000 load cell
- 80 ft conduit cable
- Magnetic transport alarm sensor with 15 ft of cable
- JB4SS junction box
- Hydraulic line locks and hoses
- 920i® Onboard Weigh Center
- Hydraulic pump not included
- Minimum 3,000 PSI recommended to maintain 2,200 PSI during lift 920i Onboard Weigh Center
- Epson® TM-U295 printer with splash shield
- Pre-installed 30 ft power cable, 30 ft home run c able and inclinometer
- Transport alarm LEDs
- Power switch
- Start/stop switch
- Waterproof enclosure
Specifications
- Capacity
- Up to 60,000 lb (30,000 kg)
- Load Cell
- RL 20000I S-beam alloy steel, 20 ft cable, IP67
- Junction Box
- JB4SS TuffSeal®
- Rating/Material
- NEMA Type 4X Stainless steel enclosure
- Power Input
- 9 to 36 VDC
- Weigh Center
- 920i® series weight controller Epson® TM-U295
- Approvals
- NTEP 15-102 Class III/IIIL Measurement Canada AM-4847
Models & part numbers
Available configurations.
| Part / model | Description |
|---|---|
| 131098 | AN15L-3 15,000 lb × 5 lb/8,000 kg × 2 kg 3-point system, OB5-SGL5 / OB10-DBL5 modules |
| 131099 | AN20L-4 20,000 lb × 5 lb/10,000 kg × 2 kg 4-point system, OB10-DBL5 (× 2) modules |
| 131101 | AN40L-4 40,000 lb × 10 lb/20,000 kg × 5 kg 4-point system, OB20-DBL10 (× 2) modules |
| 131103 | AN60L-4 60,000 lb × 10 lb/30,000 kg × 5 kg 4-point system, OB30-DBL15 (× 2) modules |
| 221327 | AN15L-3 15,000 lb × 5 lb/8,000 kg × 2 kg 3-point system, OB5-SGL5 / OB10-DBL5 modules |
| 221328 | AN20L-4 20,000 lb × 5 lb/10,000 kg × 2 kg 4-point system, OB10-DBL5 (× 2) modules |
| 221329 | AN30L-3 30,000 lb × 10 lb/15,000 kg × 5 kg 3-point system, OB10-SGL10 / OB20-DBL10 modules |
| 214818 | AN40L-4 40,000 lb × 10 lb/20,000 kg × 5 kg 4-point system, OB20-DBL10 (× 2) modules |
| 219104 | AN60L-4 60,000 lb × 10 lb/30,000 kg × 5 kg 4-point system, OB30-DBL15 (× 2) modules |
| 131442 | – |
| 154109 | – In-cab indicator 920i (requires 154112, 154111 and printer) |
| 154112 | – In-cab LED alarm assembly, 8 ft cable |
| 65635 | – Epson TM-U295 printer |
| 232439 | – Epson TM-U220II printer |
| 131811 | – Optional LED cab alarm, 35 ft |
Pricing, availability, and lead times are confirmed in your quote. Source: Rice Lake Weighing Systems 2026 Master Catalog, page 773. Specifications are subject to change without notice.
